Description

PN#6-53-201   SKU#15445  Brand: Spicer. For Use With: End Yoke Or Companion Flange. Series: 1710. Invoice: MIDSHIP TUBE SHAFT. Material: Steel. Spline: O.D. 1.958. Number Of Splines: 10. Involute: N. Fits Tube Diameter: 4.000. Fits Tube Wall: .156. Spline End To Brg Shoulder (Y): 4.062. Spline End To Weld (K) In: 5.156. Spline Length (L) In: 2.875. Thread Size: 1.250-18. Shoulder Diameter (B) In: 2.438. Shoulder Length (G) In: .812. Bearing Diameter (C) In: 1.968. VMRS: 024002060. Butt Diameter: 3.743. Style: 2. Bearing Diameter (Max): 1.9685. Bearing Diameter (Min): 1.968.
